DMF Electromagnetic Gas Safety Shut Off Valve
Product overview
Product model: DMF
Nominal diameter: DN100~1000mm
Nominal pressure: PN0.1MPa
Cut off time: one second
Medium temperature: -20~180℃
Ambient temperature: -20~60℃
DMF Electromagnetic Gas Safety Shut Off Valve description :
DMF Electromagnetic Gas Safety Shut Off Valve produced and sold by Baigang Valve Group not only overcomes the disadvantages of the electric cut-off valve which is commonly used in China at present, such as slow cut-off speed and complex control, but also can immediately cut off the gas when the power is off to ensure the safety of production.DMF type electromagnetic gas safety cut-off valve is mainly composed of electromagnetic starter and butterfly valve with good sealing performance.It has the advantages of simple structure, convenient operation, reliable operation, fast cutting speed and good sealing performance.Sealing ring is generally oil resistant rubber, can also provide special products of polytetrafluoroethylene sealing ring.
DMF Electromagnetic Gas Safety Shut Off Valve main dimensions:
DN | D | D1 | D2 | L | L1 | L2 | H | b | Z-φd |
100 | 205 | 170 | 145 | 120 | 360 | 250 | 550 | 14 | 4-18 |
150 | 260 | 225 | 200 | 145 | 410 | 250 | 590 | 16 | 8-18 |
200 | 315 | 280 | 255 | 145 | 465 | 250 | 640 | 18 | 8-18 |
250 | 370 | 335 | 310 | 180 | 520 | 250 | 690 | 22 | 12-18 |
300 | 435 | 395 | 362 | 180 | 580 | 300 | 740 | 22 | 12-23 |
350 | 485 | 445 | 412 | 200 | 630 | 300 | 790 | 22 | 12-23 |
400 | 535 | 495 | 462 | 200 | 680 | 300 | 840 | 22 | 16-23 |
450 | 590 | 550 | 518 | 200 | 740 | 300 | 880 | 24 | 16-23 |
500 | 640 | 600 | 568 | 270 | 780 | 300 | 930 | 24 | 16-23 |
600 | 755 | 705 | 670 | 270 | 895 | 400 | 1020 | 24 | 20-25 |
700 | 860 | 810 | 775 | 270 | 1010 | 400 | 1100 | 24 | 24-25 |
800 | 975 | 920 | 880 | 270 | 1125 | 400 | 1190 | 26 | 24-30 |
900 | 1075 | 1020 | 980 | 270 | 1225 | 400 | 1280 | 26 | 24-30 |
1000 | 1175 | 1120 | 1080 | 300 | 1345 | 400 | 1360 | 26 | 28-30 |
Reminder:
All text, data and pictures in this article are for reference only.To see more details of the DMF Electromagnetic Gas Safety Shut Off Valve performance parameters, structural dimension parameters, pricing, etc., or to request high quality printing samples, please Contact us.
